ADAS Perception Intern

LiDAR-based perception algorithms for autonomous driving systems

3-month internship (18 hrs/week) focusing on ADAS perception algorithms, sensor fusion, and autonomous driving systems using Velodyne LiDAR technology at LogicTronix.

Company Information

Position: ADAS Perception Intern
Company: LogicTronix [FPGA Design & Machine Learning Company]
Location: Lalitpur, Nepal
Duration: Dec 2024 - Mar 2025 (18 hrs/week)
Focus Areas: SDC, Perception, ADAS

Overview

Working with Velodyne LiDAR sensors for ADAS perception algorithm development.

Key Responsibilities

Data Acquisition & Visualization

  • Developed robust pipelines for data acquisition & visualization of Velodyne 3D LiDAR sensor data using the Point Cloud Library (PCL)
  • Implemented real-time data processing pipelines for efficient point cloud handling

Dataset Creation & Annotation

  • Annotated custom 3D point cloud datasets using 3D bounding box labeling tools (Latte)
  • Created labeled datasets for training object detection models targeting pedestrians, vehicles, and traffic objects

Point Cloud Processing & Optimization

  • Implemented voxel grid down-sampling algorithms to optimize point cloud density for computationally efficient processing
  • Developed Kd-Tree data structure from scratch in C++ to accelerate nearest-neighbor search operations on large-scale point clouds

Ground Plane Segmentation

  • Implemented RANSAC-based ground plane segmentation in C++ to effectively isolate dynamic objects such as pedestrians and vehicles from static ground surfaces
  • Optimized segmentation algorithms for real-time performance in autonomous driving scenarios

Object Detection & Classification

  • Implemented DBSCAN clustering algorithm in C++ for object detection and classification
  • Developed clustering pipelines targeting pedestrians, vehicles, and traffic objects for ADAS applications

Technical Skills

Programming Languages:

  • C++
  • Python
  • Shell scripting

Technologies & Tools:

  • Velodyne LiDAR sensors
  • Point Cloud Library (PCL)
  • ROS2 (Robot Operating System 2)
  • Linux operating systems
  • Git version control
  • 3D bounding box labeling tools (Latte)
  • Gazebo simulation environment

Algorithms & Data Structures:

  • RANSAC (Random Sample Consensus)
  • DBSCAN (Density-Based Spatial Clustering)
  • Kd-Tree implementation
  • Voxel grid down-sampling
  • Ground plane segmentation

Internship Documentation

Complete Work Report

ADAS Systems & Autonomous Driving Research

Advanced Driver Assistance Systems (ADAS) Industry Overview

  • Studied autonomous driving platforms including Waymo’s EMMA (End-to-End Multimodal Model for Autonomous Driving) using Google’s Gemini for processing sensor data and generating future trajectories
  • Analyzed Mercedes MB.OS with NVIDIA DRIVE platform integration for AI/ML components and over-the-air updates
  • Researched NVIDIA DriveOS with CUDA libraries, TensorRT for real-time AI inference, and NvMedia for sensor processing
  • Examined Tesla Autopilot’s 8-camera fusion system using RegNet, biFPN, and transformer models for feature extraction and vector space creation
  • Investigated 4D-Net for learned multimodal alignment combining 3D point clouds and RGB camera images for 3D object detection

CARLA Simulator & ROS Integration

  • Studied CARLA platform for autonomous vehicle simulation with unlimited sample generation for LiDAR training data
  • Analyzed lane finding using polynomial fitting, waypoint navigation, and object detection using CNN
  • Explored classical PID control and Stanley method for lateral and longitudinal vehicle control
  • Implemented carla-ros-bridge library for ROS communication and cv-bridge for OpenCV image conversion

ROS2 Fundamentals & Simulation

ROS2 Core Concepts

  • Mastered ROS2 fundamentals including nodes, topics, publishers, subscribers, and launch files
  • Learned RViz vs Gazebo distinction: RViz visualizes robot’s perception, Gazebo simulates physical world with forces
  • Implemented Gazebo simulation environment with URDF/SDF robot models and sensor plugins
  • Configured Gazebo-specific tags and plugins for ROS integration and sensor data publishing

ROS2 Control Framework

  • Studied ros2_control framework as kernel for ROS2 robotics systems
  • Implemented Controller Manager, Resource Manager, Hardware Components (System, Sensor, Actuator)
  • Worked with common controllers: diff_drive_controller for mobile robots, joint_trajectory_controller for articulated arms
  • Configured transmission elements for joint movement control and friction simulation

MoveIt2 Motion Planning

  • Installed and configured MoveIt2 for motion planning of industrial robots (Panda, Doosan, ABB, Fanuc, Kuka)
  • Implemented C++ motion planning using MoveIt2 interfaces without complex lambda expressions
  • Created trajectory planning with FollowJointTrajectory controllers and GripperCommand for end-effectors
  • Configured robot_state_publisher for URDF processing and TF broadcasting

LiDAR Sensor Technology & Integration

Velodyne LiDAR Systems

  • Studied Velodyne product line: VLP-16 (100m range, 360°×30° FoV), Ultra Puck, HDL-32E, and solid-state Velarray
  • Analyzed VLP-16 specifications: 300,000 points/sec, 16 channels, 2° vertical resolution, 5-20 Hz rotation rate
  • Configured VLP-16 interface with UDP packet processing, GPS synchronization, and web server monitoring
  • Implemented VeloView for real-time 3D LiDAR data visualization and processing

LiDAR Performance Metrics

  • Studied detection range (100m+ for VLP-16), range precision/accuracy, field-of-view considerations
  • Analyzed angular resolution, scan patterns, cross-talk immunity, and detection rates
  • Implemented time synchronization with GPS/PPS signals for precise data timestamps
  • Configured multiple return modes for object height measurement and vegetation analysis

ROS2 Sensor Integration

  • Integrated Velodyne LiDAR with ROS2 using velodyne_pointcloud and pointcloud_to_laserscan packages
  • Implemented laser_scan_matcher for scan matching with point cloud and IMU inputs
  • Configured sensor_msgs/PointCloud2 and sensor_msgs/LaserScan message types
  • Developed USB camera integration with ROS2 for multi-sensor fusion
  • Demo Output: 3D coordinates from 2D A1 RP LIDAR

Point Cloud Processing & Algorithms

Voxel Grid Downsampling

  • Implemented voxel grid filtering using Point Cloud Library (PCL) to reduce point cloud density for computational efficiency
  • Optimized processing pipeline for real-time performance on large-scale point clouds
  • Balanced data reduction with preservation of important geometric features

RANSAC Ground Plane Segmentation

  • Implemented RANSAC-based ground plane segmentation in C++ to isolate dynamic objects
  • Used MSAC (M-estimator Sample Consensus) variant for robust ground extraction
  • Processed point clouds to separate pedestrians, vehicles from static ground surfaces
  • Evaluated ground removal as essential preprocessing step for object detection

DBSCAN Clustering Implementation

Kd-Tree Data Structure

  • Developed Kd-Tree from scratch in C++ for accelerated nearest-neighbor search operations
  • Optimized spatial indexing for large-scale point cloud processing
  • Improved computational efficiency for real-time clustering applications

Dataset Creation & Annotation

Custom 3D Point Cloud Dataset

  • Created custom LiDAR point cloud datasets focusing on pedestrian and vehicle detection
  • Collected and processed VLP-16 data with quality assessment using Veloview visualization
  • Addressed sparse point cloud challenges at different distances (density variation formula: d = 2 × r × tan(θ/2))

LiDAR Annotation Tools

  • Evaluated annotation tools: LabelCloud (Velodyne official), Autoware.AI, Scale AI, CVAT, Latte
  • Implemented Latte (3D-bat fork) for single-click 3D bounding box annotation on point clouds
  • Used sensor fusion approach with image-based detection algorithms for pre-labeling
  • Projected 2D image segmentation masks to 3D point clouds for automated labeling

KITTI Dataset Format

  • Converted custom datasets to KITTI format with 14-field array structure
  • Implemented 3D bounding box format: height, width, length, x, y, z, rotation_y
  • Added 2D bounding boxes for camera images and shared fields (truncation, occlusion, class)
  • Validated annotation quality through visualization and comparison with KITTI labeled data

LiDAR Calibration

  • Studied intrinsic calibration for internal timing and distortion corrections
  • Analyzed extrinsic calibration for sensor alignment with cameras and IMUs
  • Addressed VLP-16 systematic errors: vertical/horizontal rotation offsets, distance offsets
  • Implemented calibration procedures for improved localization and mapping precision

Deep Learning Frameworks for 3D Object Detection

PointPillars Architecture

  • Studied PointPillars: lightweight 3D object detection using pseudo-image conversion and 2D CNN
  • Analyzed feature encoder using PointNets for point cloud representation in vertical pillars
  • Examined 2D CNN backbone for high-level feature processing and detection head for 3D box generation
  • Compared with PV-RCNN (accurate but expensive) and SECOND (sparse 3D CNNs)

OpenPCDet & MMDetection3D

  • Explored deep learning frameworks: OpenPCDet (PyTorch-based), MMDetection3D
  • Studied data format requirements: voxelized format for SECOND, BEV for PointPillars, raw point cloud for PointRCNN
  • Analyzed model architectures and computational trade-offs for real-time applications

Research Findings & Performance Analysis

Clustering Algorithm Comparison

  • DBSCAN outperformed K-means for arbitrarily shaped clusters (vehicles, pedestrians)
  • K-means showed better internal validation indexes but visually over-segmented objects
  • DBSCAN struggled with closely spaced objects, merging them into single clusters
  • Ground removal (RANSAC/MSAC) significantly improved clustering quality in all scenarios
  • DBSCAN preferred for urban scenarios with multiple objects; K-means less suitable for highway scenes

Distance-Based Clustering Challenges

  • Identified point cloud density variation with distance: 8.38cm at 2.4m vs 39.5cm at 11.3m for VLP-16
  • Analyzed under-segmentation (threshold too large) and over-segmentation (threshold too small) issues
  • Implemented circular zone division approach: nested circular regions with adaptive distance thresholds
  • Applied ring-based segmentation with 2.8m width and 0.1m increments for reliable human detection

Technical Challenges & Solutions

  • Resolved network configuration issues in Gazebo by editing /etc/hosts file
  • Fixed MoveIt2 installation errors by installing missing packages and header files
  • Addressed git conflicts using rebase and resolved large file upload issues with Git LFS
  • Implemented proper rosdep update procedures without sudo to avoid permission errors

Key Learnings

  • Hands-on experience with industrial-grade Velodyne LiDAR sensors and point cloud processing
  • Deep understanding of autonomous driving perception algorithms and ADAS systems
  • Real-time C++ development for safety-critical applications
  • Professional software development practices in FPGA and ML company environment
  • Practical implementation of advanced algorithms (RANSAC, DBSCAN, Kd-Tree) for perception tasks
  • Experience with ROS2 ecosystem and sensor integration for autonomous systems

This internship provided comprehensive experience in ADAS perception development, from raw sensor data processing to object detection and classification, essential for autonomous driving systems.
